Description
Cummins Biogas Generator Set/CHP
Rated capacity as above is based on 50Hz, while 60Hz is available too;
Alternator brands for option: Leroy Somer, Stamford, Marathon and Sinocox; Control panel brands for option: ComAp, Deep Sea, Harsen and Smartgen;
Ignition brands for option: Altronic, WoodWard and MOTORTECH; Automatic air&fuel ratio control system, automatic oil feed device are available;
Grid synchronization panel, containerized package, exhaust purification system can be provided according to customers specific requirements;
Heat recovery system for combined heat and power plant is available;
Warranty: 1 Year or 5000 Hours which comes firstly, can provide service of on-site maintenance and supply spare parts during the whole life of machine;
| Set Model |
Rated Capacity (KW) |
Engine Model |
Dimension (mm) |
Weight (kg) |
| ACG24 | 24 | HG4B | 1350×750×1250 | 1050 |
| ACG30 | 30 | HG4B | 1350×750×1250 | 1050 |
| ACG40 | 40 | HGT4B | 1350×750×1250 | 1090 |
| ACG50 | 50 | HG6B | 2250×820×1500 | 1100 |
| ACG80 | 80 | HGT6B | 2250×820×1550 | 1200 |
| ACG120 | 120 | HGT6C | 3300×1300×1900 | 1750 |
| ACG120 | 120 | HGN14 | 3500×1500×1990 | 3630 |
| ACG150 | 150 | HGT6L | 3300×1300×1900 | 2800 |
| ACG160 | 160 | HGNT14 | 3500×1500×1990 | 3680 |
| ACG200 | 200 | HGNT14 | 3500×1500×1990 | 3680 |
| ACG250 | 250 | HGKT19 | 4000×1250×2020 | 4250 |
| ACG300 | 300 | HGKT19 | 4000×1250×2020 | 4450 |
| ACG400 | 400 | HGKT38 | 5150×1550×2200 | 7780 |
| ACG500 | 500 | HGKT38 | 5150×1550×2200 | 7890 |
